ST Nucleo F401RE

Description

The STM32 Nucleo boards line is proposing a very affordable solution with high connectivity means. Indeed, the Arduino™ connectivity support and ST Morpho headers make it easy to expand the functionality of the STM32 Nucleo open development platform with a wide choice of specialized shields.

In addition, the Nucleo-F401RE board does not require any separate probe as it integrates the ST-LINK/V2-1 debugger/programmer: the board can be directly connected to the PC !

Each STM32 Nucleo board allows agile development with fine-tuning of both hardware and software on-the-fly at each prototyping stage. Investment in application shields is also protected as most shields can be used across various projects leveraging the scalability and diversity of the STM32 family.

Features

  • One high-performance STM32F401RET6 microcontroller with LQFP64 package
    • ARM Cortex-M4 CPU with FPU at 84MHz
    • 512 KBytes Flash
    • 12bit ADC 2.4 Msps up to 10 channels
    • Up to 10 timers
    • Up to 3x I2C, 3x USARTs, 4x SPIs, SDIO
    • USB 2.0 Full Speed with on-chip PHY
    • 96bit unique ID
  • Two types of extension resources
    • Arduino Uno Revision 3 connectivity
    • STMicroelectronics Morpho extension pin headers for full access to all STM32F401RET6 I/Os
  • Flexible board power supply: USB VBUS or external source (3.5 V, 5 V, 7 V - 12 V)
  • On-board ST-LINK/V2.1 interfacing with the PC, with three different communication channels via USB
    • Debug and programming port, to use STM32 Nucleo wth standard toolchains/debuggers/programmers
    • Virtual Com port to send back traces to the PC
    • Mass storage (USB Disk drive) for drag'n'drop programming
" ["DOCUMENT_INFO"]=> string(0) "" ["WARRANTY_INFO"]=> string(0) "" ["DELIVERY_INFO"]=> string(0) "" ["IS_VIDEO_ACTIVE"]=> string(1) "0" ["NOTES"]=> string(0) "" ["TAGS"]=> array(0) { } ["IS_ORDER_NOTE_ACTIVE"]=> bool(false) ["IS_CASH_POINT_ACTIVE"]=> bool(false) ["IS_RELATED_PRODUCTS_ACTIVE"]=> bool(false) ["DISPLAY_GAIN"]=> bool(false) }

ST Nucleo F401RE Geliştirme Kiti

STM
Stok Kodu : CFJLNTZ4
62,95 TL +KDV
74,28 TL KDV Dahil
Paylaş:
  • Ürün Özellikleri
  • Ödeme Seçenekleri
  • Yorumlar (0)
  • Resimler
  • ST Nucleo F401RE

    Description

    The STM32 Nucleo boards line is proposing a very affordable solution with high connectivity means. Indeed, the Arduino™ connectivity support and ST Morpho headers make it easy to expand the functionality of the STM32 Nucleo open development platform with a wide choice of specialized shields.

    In addition, the Nucleo-F401RE board does not require any separate probe as it integrates the ST-LINK/V2-1 debugger/programmer: the board can be directly connected to the PC !

    Each STM32 Nucleo board allows agile development with fine-tuning of both hardware and software on-the-fly at each prototyping stage. Investment in application shields is also protected as most shields can be used across various projects leveraging the scalability and diversity of the STM32 family.

    Features

    • One high-performance STM32F401RET6 microcontroller with LQFP64 package
      • ARM Cortex-M4 CPU with FPU at 84MHz
      • 512 KBytes Flash
      • 12bit ADC 2.4 Msps up to 10 channels
      • Up to 10 timers
      • Up to 3x I2C, 3x USARTs, 4x SPIs, SDIO
      • USB 2.0 Full Speed with on-chip PHY
      • 96bit unique ID
    • Two types of extension resources
      • Arduino Uno Revision 3 connectivity
      • STMicroelectronics Morpho extension pin headers for full access to all STM32F401RET6 I/Os
    • Flexible board power supply: USB VBUS or external source (3.5 V, 5 V, 7 V - 12 V)
    • On-board ST-LINK/V2.1 interfacing with the PC, with three different communication channels via USB
      • Debug and programming port, to use STM32 Nucleo wth standard toolchains/debuggers/programmers
      • Virtual Com port to send back traces to the PC
      • Mass storage (USB Disk drive) for drag'n'drop programming
