PC Osiloskop (2X20Mhz/48MS/s)

Stok Kodu : NQSFRQRST
429,01 TL +KDV
506,24 TL KDV Dahil
Paylaş:
  • Ürün Özellikleri
  • Ödeme Seçenekleri
  • Yorumlar (0)
  • Resimler
  • PC Osiloskop + Lojik Analizör + Spectrum Analizör



    USB portundan beslemesini alır ekstra besleme gerekmez. Ürün 4 fonksiyon içermektedir.

    • 2 Kanal osiloskop (48MS/s)
    • 16 kanal lojik analizör
    • Spectrum analizör
    • Data logger

    Fiyata dahil olanlar

    • ISDS205C PC osiloskop cihazı
    • 2 adet 60MHz probe
    • USB kablo
    • Lojik analizör için dupont kablo ve klips
    • Ürün CD'si

    Digital Storage Oscilloscope

    Passage

    2

    Impedance

    1MΩ 25pF

    Coupling

    AC/DC

    Vertical resolution

    8Bit

    Voltage range

    6V ~ 6V (probe X1)

    -60V ~ 60V (probe X10)

    Vertical accuracy

    ±3%

    Timebase range

    1ns-20s

    Vertical adjustable

    10mV/div-10V/div1MΩ

    Input protection

    DiodeClamping

    Automatically set

    Have(10Hz to 20MHz)

    Trigger

    Automatic, continuous, single

    Trigger Slope

    +/-

    Trigger level adjustable

    Have

    Trigger Type

    Simulation

    Trigger Source

    Cspan, CH2

    Memory Depth

    1MB/CH

    Single bandwidth

    20MHz

    Maximum real-time sampling rate

    48MS/s

    Sampling Rate Selection

    Have

    Vertical mode

    Cspan, CH2, ADD, SUB, MUL

    Display Mode

    XAlternatively, Y and X-Y mode alternately

    Cursor measurements

    Have

    Cursor display

    Frequency, voltage

    Waveform save format

    Osc (private), Excel and Bmp



    Spectrum Analyzer

    Passage

    2

    Bandwidth

    20MHz

    Algorithm

    FFT(18 kinds of window), correlation, power spectrum

    FFT data points

    8-1048576Per channel

    Filtering

    FIR supports arbitrary amplitude frequency sampling method and Rectangle, bartlett, triangular, cosine, hanning, bartlett_hanning, hamming, blackman, blackman_Harris, tukey, Nuttall, FlatTop, Bohman, Parzen, Lanczos, kaiser, gauss window function method;

    IIR filter support 'Butterworth', 'Chebyshev I', 'Chebyshev II', 'oval' type;



    Data Logger

    Passage

    2Passage

    Impedance

    1MΩ 25pF

    Coupling

    AC/DC

    Vertical resolution

    8Bit

    Voltage range

    -6V~6V(ProbeX1)

    -60V~60V(ProbeX10)

    Sampling Rate

    1 channel:1K~24M Hz

    2 channel:1K~16M Hz

    Log file

    Max 4G, with the sampling rate for recording time



    Logic Analyzers

    Number of Channels

    16

    Sampling Rate

    8Passage: 250K~24M Hz

    16Passage: 250K~16M Hz

    Sampling points

    1MB-2GBB



    Logic AnalyzersSaleae Logic

    Number of Channels

    8

    Sampling Rate

    25K~24M Hz

    Protocol Analysis

    Atmel SWI BiSS CSPII2CCANUARTI2S/PCMDMX-512JTAGLINManchester1-WIREUNI/OSimple ParallelMDIOUSB1.1PS/2 Keyboard/Mouse

    Sampling points

    1MB~10TB
