TPA3116 D2 Dual Channel Digital Sound Amplifier Module

Yorum Yap

Marka/Menşei:TZT

Stok Kodu:18669

302,46 TL + VAT

362,95 TL

KDV Dahil

Alışveriş Listeme Ekle

Fiyatı Düşünce Haber Ver

1500₺ ve üzeri kargo ücretsiz.

Dual Channel Digital Sound Amplifier Module

TPA3116 D2 Modulespeaker amplifier board with DC 12-26V input, can realize universal audio amplifier receiver and sound quality well. You can enjoy incredible stereo sound with 2x120W left and right dual channel audio output stereo amplifier board. Large heat sink, overheat proof Stereo audio amplifier module provides over 90% efficiency and high accuracy. Can be used in DIY amplifier board, DIY bookshelf speaker, car audio components, home theater audio system and more.

TPA3116 D2 Dual Channel Digital Audio Amplifier Module Technical Specifications

Manufacturer	TZT
Product Category	Bluetooth Audio and Amplifier Modules
Sherry	XH - M543
Chip Type	TPA3116D2 * 1
Output Voltage	DC 12V ~ 26V (24V recommended)
Output Power	Max 2x120W
Signal-to-Noise Ratio	100dB
Audio Path	Dual Channel
Appearance Size	Approx.92 x 68 x 17mm

Instructions for Use

1) Power Supply:	Use DC 12-26V voltage power supply (suggest to use 24V)
2) Audio Input:	Small 3P terminal input and about 30 cm special audio terminal line.
3) Power Output:	Please connect the speaker to the OUT output of the board. Pay attention to the positive and negative poles! 4 ohm speaker is recommended.
4) Sound Adjustment:	Potentiometers on both sides of the audio input terminal correspond to the left and right audio tracks, respectively. Rotate the sound with a screwdriver.
