Raspberry Pi 3 Model B + Plus

Raspberry Pi 3 B + (Raspberry Pi Model B Plus 3)

Raspberry Pi 3 Has Been Renewed!Raspberry Pi Model B 3 (Raspberry Pi 3)Raspberry Pi Model B + 3It appears with its renewed features.Raspberry Pi 3the last product of the familyRaspberry Pi 3 B +The model draws our attention with its renewed features, increasing the processing power and connection speeds. Raspberry Pi 3 model B + comes with the same design as the previous model B, so it can be easily used with boxes and cooling systems compatible with old models, if any.

Key differences between Raspberry Pi 3 Model B and B +If we will mention:

• Raspberry Pi 3 B + comes with an additional + 200Mhz faster processor than the previous model. In addition, the metal cover on the processor provides better cooling.
• Although the new processor is faster, it consumes less energy. (More efficient processor)
• The renewed B + comes with 802.11 b / g / n / ac support, which offers 2.4GHz and 5GHz wireless connectivity.
• Raspberry Pi 3 B +Provides power supply via Ethernet connection, for which PoE HAT expansion board is required.
• It offers 330Mbit connection with its renewed Ethernet connection.

Raspberry Pi Model B + 3 - Features of Raspberry Pi 3 B +

• BCM2837B0, Cortex-A53 64-bit 1.4GHz processor
• 1 GB LPDDR2 SDRAM
• 2.4GHz and 5GHz IEEE 802.11.b / g / n / ac wireless LAN, Bluetooth 4.2, BLE
• Gigabit Ethernet over USB 2.0 (maximum throughput 300 Mbps)
• Extended 40 pin GPIO header
• Full size HDMI
• 4 USB 2.0 ports
• CSI camera port
• DSI touch screen port
• Video and audio output port (4 jack output)
• Micro SD port for loading your operating system and storing data
• 5V / 2.5A DC power input
• Power over Ethernet (PoE) support (requires separate PoE HAT expansion card)

Documents

• Raspberry Pi 3 Model B + FeaturesCheck the file.
• Raspberry Pi 3 Model B + Mechanical SchematicCheck the file.
• Raspberry Pi 3 Model B + SchematicCheck the file.
