MT3608 2A Amplifier DC-DC Progressive Power Module (Arduino)

MT3608 2A Max DC-DC Progressive Power Module - Arduino Compatible Voltage Regulator

MT3608 2A Max DC-DC Progressive Power Moduleproduct ofArduinoIt is a amplifier board that increases the input value in the range of 2V and 24V up to 28V. It gives an output up to 2A. This product provides an easy, fast and inexpensive solution in projects where you have low voltage problems or when there is a voltage mismatch between components. It provides a great advantage that it does not take up space in the circuits with its minimal dimensions. The output voltage must be higher than the input voltage otherwise the circuit will not work. You can adjust the output voltage according to your wish through the trimpot.

MT3608 2A Max DC-DC Progressive Power Module (Arduino) Technical Specifications:

• Maximum Output Current: 2A
• Input Voltage: 2V - 24V
• Maximum Output Voltage: 28V
• Efficiency: Max.93%
• Product Size: 36mm * 17mm * 14mm

Warning:

When using the MT3608 2A Step-up Converter module, you can adjust the output voltage by turning the trimpot on it counterclockwise as in the image below. If you turn it in the opposite direction too much, it is possible to burn the module because the trimpot will short circuit.
