MPX5010DP Pressure Sensor

MPX5010DP Differential Pressure Sensor

Freescale MPX5010DP Pressure Sensor is a temperature compensated and offset calibrated differential pressure sensor. The sensor, which uses strain-gauge technique using a sensor with high sensitivity and linearity, gives a 25mV full-scale signal to the differential pressure between 0-10 kPascal.

MPX5010DP Differential Pressure Sensor Features

• Pressure measurement range: 0-10kPascal = 0-1.45Psi = 0.1Bar = 75mmHg = 1019.78mmH2O
• Maximum Pressure: 40kPa
• Working voltage: 4.75V-5.25V
• Working current: 5mA - 10mA
• Full scale output voltage:
  • Min: 4,475V
  • Typical: 4.7V
  • Max: 4,925mV
• Output voltage Offset (scale offset): 0mV 0.425mV
• Accuracy: 450mV / mm / 4,413mV / mmH2O
• Linearity: + - 5%
• Output Current max: 0.1mA

For the product's PDF fileclick here.
