JQX-15F-T90-1H-24VDC 24V 30A 5 Pin Relay

24V 30A Amp Relay JQX-15F-T90-1H-24VDC

RelayIt is a mechanical switching unit that can be controlled electrically. It consists of two main parts: relay coil and contactors. The relay coil, over which current flows, creates a magnetic field and attracts the contacts. Thus, relay contacts change position.

It is one of the circuit components preferred in telecom applications, gas detector circuits, RF control applications, Infrared control applications, small volume circuits (gum relay) etc.

It is used in the control of load currents between 1A-40A at operating voltages of 5V, 9V, 12V, 24V, 48V, 220V. Single and multiple contact output possibilities are available.

JQX-15F-T90-1H-24VDC 24V 30A 5 Pin Relay Technical Specifications

Manufacturer: ASIA DRAGON

Relay Type: RELAY POWER

Mounting Type: THT

Contact Form: SPST-NO (1 Form A)

Coil Type: Non Latching

Contact Current: 30A

Coil Voltage: 24VDC

Coil Current: N / A

Contact Voltage: 240VAC / 28VDC

Coil Resistance: 660R

Coil Power 900mW

Working Temperature: N / A

Number of Pin: 5PIN

Dimensions (mm) WxLxH: 20.00x32.20x20.10

Rohs: ROHS
