HMC5883L 3-Axis Compass Sensor - Magnetometer - GY-271

HMC5883L 3-Axis Compass Sensor - Magnetometer - GY-271

HMC5883L is a 3-axis compass sensor.Itmagnetometer moduleIt works with HMC5883L sensor as well as voltage regulator. In this way, it can be used easily in different systems and applications. It provides ease of use in breadboards and circuits with its standard pin scheme.

The sensor uses the I2C communication protocol. The voltage regulator on the module makes it possible to work with a supply voltage of 3-5V.

HMC5883L 3-Axis Compass Sensor - Magnetometer - GY-271 Features

• Input Voltage: 3-5V
• Sensor Output: Digital I2C Communication Protocol
• Measurement Range: ± 1.3-8 Gauss
• Board Dimensions: 14x13mm

Documents

• HMC5883L- 3-Axis Compass Sensor DatasheetCheck the file.
• HMC5883L-3 Arduino Sample ApplicationCheck the file.
• HMC5883L-3 Arduino LibraryCheck the file.
