Arduino Compatible 433Mhz RF Receiver Module - WL101-341

WL101 - 341 433Mhz RF Receiver - Arduino Compatible

RF Receiver Module,It is a board that you can connect to your Arduino and control other modules and products such as LED, light, alarm, garage door, relay, etc. wirelessly. You can examine the pin outputs of the board and the Arduino connection in the documents section.

433Mhz RF Receiver Technical Specifications

• Supports ASK / OOK modulation
• Receiver sensitivity: 108dBm
• Operating frequency: 433.92 MHz, bandwidth about ± 150 KHz;
• Input voltage range: 2.2V-5V;
• Working current: 2.1mA
• Steady state current: 1uA
• Multiple transmission rates, for general module: 2 KHz, up to 10 KHz;
• Temperature range: -40/85 ° C
• Size: 30 × 9 × 1 (mm) (can be customized according to customer)
• External antenna: 32CM single core wire can be used

Documents

• Pin and Arduino Connection DiagramCheck the file.

Useful Links

• RF Module TypesYou can examine.
