Arduino Pro Mini 5V 16Mhz Clone

Arduino Pro Mini 5V 16Mhz Clone

It is a development / prototype board that works with Arduino Pro Mini 5V and has an Atmega328 microcontroller on it. (When we send the code to the Arduino Pro Mini, it is necessary to press the reset button once at the loading stage.) The point that distinguishes the Arduino Pro Mini from other cards is that there is no USB input or interface, so a simple FTDI to program the Arduino Pro Mini you need to install the programs with the programmer).

If you do not want to use FTDI, there is a USB interfaceArduino Pro Micro 5V 16MhzYou can review the version.

Clone Arduino Pro Mini 5V 16Mhz Specifications

• ATmega328 operating at 16 MHz
• Auto-reset support
• 5V regulator circuit
• Max 150mA output
• Over current protection
• DC input between 5-12V
• Analog Pin number: 8
• Number of digital I / O pins: 14
• Length: 33 mm
• Width: 18 mm
• Weight:<2 gram

What is Arduino?

ArduinoIt is an open source electronic platform that offers easy-to-use software and hardware. It is designed for anyone to easily develop prototypes and make interactive projects. BasicallyATMEL microcontrollersUsing the Arduino platform, with its libraries developing over the years and the community that wrote these libraries, it offers easy and accessible solutions for anyone who wants to improve themselves in the field of electronics and programming.

Arduino is an open source platform, that is, all products, related software and designs of Arduino are openly shared with everyone. This allows anyone who wants to produce Arduino, and many electronics companies around the world produce Arduino clones. This is beneficial in terms of offering many types and price ranges to users.

The more popular and useful the Arduino's hardware is, the more useful and popular its software is. Arduino software development platform (IDE) can be used not only for Arduino but also for different development / prototype boards in the electronics market. With its numerous libraries, you can find the libraries you are looking for for any kind of expansion board you want. Libraries can be uploaded through the Arduino software development platform without any problem.

Documents

• Arduino Pro Mini Pinout DiagramCheck the file.
• Arduino Software Development Platform (IDE)Check out the page.
