50W Red Power Leds

50W Red Power Leds

50W red Power Led Module. Running with 32-34VDC 1.5A and need to be installed in the Cold chassis. As normal lamps can withstand a high temperature, LED Lamps should not exceed 60 to 70 °C. The maximum permanent current is 1.4 when it is run and the required cooling has a lifetime of up to 50000 hours.

50W Red Power Led Properties

• Brand: HQG
• Model: AXD-50WGJ24WW
• Figure: Tetragon
• internal link: 10 strings 5 rows
• Color: Red 620nm-630nm
• Light Power: 850-900lm
• Light Angle: 120 °
• Color mixture index: 60-85
• Max. Power Consumption: 50W
• Operating Voltage: 32-34V
• Max Reverse Voltage: 50V
• Max Stream: 1.5A
• Recommended Stream: 1.4A
• Ambient operating temperature: -20 °C to + 60 °C
• Hull Material: Pure Copper plate
• Lamp life: 50000 hours
• Eligibility to dim: Yes can be done with PWM or current control.
