1kg Load Cell + Hx711 Module Weight Kit

1kg Load Cell + Hx711 Module Weight Kit

1kg Load Cell + Hx711 Module Weight setIt offers you the Hx711 communication card and 1 kg weight sensor in one package. Hx711 card allows you to transfer the analog weight value detected in the load cell to digital data and transfer it to your microprocessor.

Technical Specifications of 1kg Load Cell + Hx711 Module Weight Kit

• Load Cell Capacity: 1 kg
• Splitter Input Voltage: ± 40mV
• Data Precision: 24 bit (24 bit A / D Converter Integrated)
• Refresh Frequency: 80 Hz
• Working Voltage: 4.8 - 5.5V
• Output voltage range: 2.6V ~ 5.5V
• Working current:<10 mA
• Card Size: 34.5mm x 20.5mm x 1.1mm
• Loadcell Size: 80mm x 12.7mm x 12.7mm

Power Cell Connections:

• Red: Power +
• Black: Power -
• Green: Signal +
• White: Signal -

Documents

• Hx711 DatasheetCheck the file.
