1Hz-150Khz Lcd Display Signal Generator Module XY-LPWM

Marka/Menşei: Diymore
Stok Kodu : 18257

101.86 TL + KDV
122.23 TL KDV Dahil
Out of stock Alert when in stock
Share:
  • Features
  • Payment Options
  • Comments (0)
  • Images

  • 1Hz-150Khz Lcd Display Signal Generator Module

    1Hz-150Khz Lcd Display Signal Generator Module,PWM is capable of generating a square wave signal for experimental development involving speed control (e.g. motor drives) and other microcontroller uses. Serial Protocol can be controlled by TTL (TXD and RXD pins). It is stable and reliable and very simple to use.

    1Hz-150Khz Lcd Display Signal Generator Module Technical Specifications

    ManufacturerGreatzt
    Product CategorySignal Generator
    SherryXY-LPWM
    Operating voltage3.3 ~ 30 VDC
    Frequency range1Hz - 150 KHz
    Frequency AccuracyAccuracy in each range is about 2%.
    Signal Load Capacity5 ~ 30 mA
    Output AmplitudePWM Amplitude Equal To Supply Voltage
    Operating temperature-20 ° C ~ + 70 ° C
    Dimensions52 x 32 x 10 mm
    9600 Bps Data Bits8
    Stop Bitone
    Check DigitNo
    Flow ControlNo

    Adjustment Parameters:

    1) Setting the Frequency of the PWM

    "F101" komutu: Frekansı 101 HZ (001 ila 999) olarak ayarlayın.

    "F1.05" komutu: 1.05 KHZ (1.00 ~ 9.99) sıklığını ayarlayın.

    "F10.5" komutu: Frekansı 10.5KHZ (10.0 ~ 99.9) olarak ayarlayın.

    "F1.0.5" komutu: 105KHZ (1.0.0 ~ 1.5.0) frekansını ayarlayın.

    2) Adjusting the PWM Duty Cycle

    D X X X ": PWM görev çevrimini X X X olarak ayarlayın; (001 ~ 100)

    Example: “D050” determines that the PWM duty cycle is 50%

    3) Read Set Parameter

    Ayarlanan parametreleri okumak için bir "read" dizisi gönderin.

    Returned successfully: DOWN

    Setup failed to return: FALL

    Useful Links
